Double maintenance, no fan, no noise, low power to truly achieve peace of mind, effort and time for customers.
| RX Series Parameters | ||
| Item | P1.56 | P1.95 |
| Pixel Pitch | 1.5625mm | 1.953mm |
| LED Type | SMD3IN1-MPI1010 | SMD3IN1-MPI1010 |
| Module Resolution | 160dots x 160dots | 128dots x 128dots |
| Driving Mode | 1/40scan | 1/32scan |
| Module Pixels | 25,600dots | 16,384dots |
| Module Size(mm) | 250 x 250 | 250 x 250 |
| Cabinet Size(mm) | 500 x 500 | 500 x 500 |
| Cabinet Resolution(dots) | 320 x 320dots | 256 x 256dots |
| Pixel Density(dots/m²) | 409,600 | 262,144 |
| Minimum Viewing Distance | ≥1.5m | ≥1.9m |
| Brightness | 3500~4000cd/m² | 3500~4000cd/m² |
| IP Grade | IP65 | IP65 |
| Refresh Rate | 3840Hz~7,680Hz | 3840Hz~7,680Hz |
| Gray Scale | 12~16bits | 12~16bits |
| Viewing Angle | 160°/160° | 160°/160° |
| Maximum Power Consumption | 800(W/m²) | 800(W/m²) |
| Average Power Consumption | 270(W/m²) | 270(W/m²) |
| Inout Voltage | AC110V~AC220V 50Hz/60Hz | AC110V~AC220V 50Hz/60Hz |
| Operating Temperature | -20℃~60℃ | -20℃~60℃ |
| Operating Humidity | 10%~90% | 10%~90% |
| Cabinet Material | Die-casting Aluminum | Die-casting Aluminum |
| Cabinet Weight | 7.5kg/panel | 7.5kg/panel |
| Operating System | Windows (Win7, Win8, etc.) | Windows (Win7, Win10, etc.) |
| Signal Source Compatibility | DVI, HDMI1.3, DP1.2, SDI, HDMI2.0, etc | DVI, HDMI1.3, DP1.2, SDI, HDMI2.0, etc |
| LED Display Type | Small pitch LED panel | |
