| Item | P1.5 | P1.86 | P1.875 | P2 | P2.5 | P3 | P3.07 | P4 | P5 |
| Pixel Pitch | 1.56mm | 1.86mm | 1.875mm | 2mm | 2.5mm | 3mm | 3.07mm | 4mm | 5mm |
| LED Type | SMD1212 | SMD1515 | SMD1515 | SMD1515 | SMD2020 | SMD2020 | SMD2020 | SMD2020 | SMD2020 |
| Module Resolutlon | 1330dotsx100dots or 213dots x 107dots | 172dots*86dots | 128dotsx64dots | 128dotsx64dots | 96dotsx48dots | 80dots×40dots | 104dots*52dots | 64dots*32dots | 64dots*32dots |
| or 1286ots*64dots | or 64dotsx64dots | ||||||||
| Driving Mode | 1/48scan | 1/43scan | 1/32scan | 1/32scan | 1/24scan | 1/20scan | 1/26scan | 1/16scan | 1/13scan |
| or 1/52scan | or 1/32scan | or 1/32scan | |||||||
| Module Pixels | 13,300dots | 14,792dots | 8,192dots | 8,192dots | 4,608dots | 3,200dots | 5,408dots | 2,048dots | 2,048dots |
| or 22,791dots | or 8,192dots | or 4,096dois | |||||||
| Module Size | 200mm ×150mm | 320mm×160mm | 240mmx120mm | 256mm×128mm | 240mm*120mm | 240mmx120mm | 320mmx160mm | 256mm×128mm | 320mmx160mo |
| br 320mm ×160mm | or 320mmx160mm | or 192mmx192mm | |||||||
| Cabinet Size | Customized | Customized | Customzed | Customized | Customized | Customized | Customized | Customized | Customlzed |
| Cabinet Resolutlon | Customled | Customized | Customlzed | Customized | Customized | Customized | Customzed | Customzed | Customlzed |
| Pixel Density | 443,333.3 dots/m² | 288,906.25 dots/m² | 288,444.44 dots/m² | 250,000 dots/m² | 160,000 dots/m² | 11,111.11 dots/m² | 105,625 dots/m² | 62,500 dots/m² | 40,000 dots/m² |
| or 445,136.7 dots/m² | |||||||||
| Minimum Viewing Distance | ≥1.5m | ≥1.86m | ≥1.875m | ≥2m | ≥2.5m | ≥3m | ≥3.07m | ≥4m | ≥5m |
| Brightness | 500nits-600nits | ||||||||
| IPGrado | IP43 | ||||||||
| Rofresh Rate | 1,920Hz-3,840Hz | ||||||||
| Gray Scale | 13bits-24bits | ||||||||
| Viewing Angle | H:160°/V:160° | ||||||||
| Maximum Power Consumption | 500W/m² | ||||||||
| Average Power Consumption | 180W/m² | ||||||||
| Input Voltage | AC110V-AC220V 50Hz/60Hz | ||||||||
| Operating Temperature | -30C~50℃ | ||||||||
| Operating Humidity | 10%~90% | ||||||||
| Cabinet Material | Iron | ||||||||
| Cabinet Weight | 20kg/m² | ||||||||
| Operating System | Windows (Win7,Win8,etc.) | ||||||||
| Signal Source Compatibility | DVI,HDMI1.3,DP1.2.SDI,HDMI2.0, etc. | ||||||||
