Variety of unit modules sizes are available. Seamless match perfect for diferent cabinet sizes. High brigtness, waterproof, high refresh rate. SMD package offers wide viewing angle. Offers super high defnition image quality. Top grade quality, high end confguration, wholesale price.
| OM | |||||
| Technical Specifcations | P3.91 | P4 | P 4.81 | P5 | P 5.95 |
| Pixel Pitch | 3.91 mm | 4 mm | 4.81 mm | 5 mm | 5.95 mm |
| Pixel Configuration | SMD1921 | SMD1921 | SMD2727 | SMD2727 | SMD2727 |
| Module Size | 250×250mm | 256×128 mm | 250×250 mm | 320×160mm | 250×250mm |
| 320×160mm | |||||
| Module Resolution | 64×64 dots | 64×32 dots | 52×52 dots | 64×32 dots | 42×42 dots |
| 80×40 dots | |||||
| Pixel Resolution | 65,536 dots/m² | 62,500 dots/m² | 43,264 dots/m² | 40,000 dots/m² | 28,224 dots/m² |
| Best Viewing Distance | 4m-30m | 4m-30m | 5m-30m | 5m-60m | 6m-60m |
| Brightness | 3500 cd/m² | 5,500-6,000 cd/m² | 3,800 cd/m² | 6,000 cd/m² | 3,500~3,800 cd/m² |
| View Angel | 110°(W);110°(H) | 110°(W);110°(H) | 110°(W);110°(H) | 110°(W);110°(H) | 110°(W);110°(H) |
| Refresh Rate | ≥1,920 HZ | ≥1,920 HZ | ≥1,920 HZ | ≥1,920 HZ | ≥1,920 HZ |
| Input Voltage | AC110V-220V±10% | AC110V-220V±10% | AC110V-220V±10% | AC110V-220V±10% | AC110V-220V±10% |
| Max.Power Consumption | ≤560W/m² | ≤900W/m² | ≤560W/m² | ≤780W/m² | ≤780W/m² |
| Avg.Power Consumption | 230W/m² | 360W/m² | 230W/m² | 320W/m² | 320W/m² |
| Storage Temperature | -20 ℃~+50℃ | -20 ℃~+50℃ | -20 ℃~+50℃ | -20 ℃~+50℃ | -20 ℃~+50℃ |
| Working Temperature | -35 ℃~+85 ℃ | -35 ℃~+85 ℃ | -35 ℃~+85 ℃ | -35 ℃~+85 ℃ | -35 ℃~+85 ℃ |
| Working Humidity | 10%~95% | 10%~95% | 10%~95% | 10%~95% | 10%~95% |
| Lifespan | ≥9,000hours | 29,000 hours | 29,000hours | 29,000hours | 29,000 hours |
| (50% brightness) | |||||
| Maintenance Mode | Front/Rear | Front/Rear | Front/Rear | Front/Rear | Front/Rear |
| OM | ||||
| Technical Specifcations | P6 | P6.67 | P8 | P 10 |
| Pixel Pitch | 6mm | 6.67 mm | 8mm | 10mm |
| Pixel Configuration | SMD2727 | SMD3535 | SMD3535 | SMD3535 |
| Module Size | 192×192 mm | 320×160mm | 256×128 mm | 320×160 mm |
| 320×160 mm | ||||
| Module Resolution | 32×32 dots | 48×24 dots | 32×16 dots | 32×16 dots |
| 40×20 dots | ||||
| Pixel Resolution | 27,777 dots/m² | 22,500 dots/m² | 15,625 dots/m² | 10,000 dots/m² |
| Best Viewing Distance | 6m-60m | 7m-60m | 8m-60m | 10m-100m |
| Brightness | 6,200 cd/m² | 6,500 cd/m² | 5,500-6,500 cd/m² | 5,500-6,500 cd/m² |
| View Angel | 110°(W);110°(H) | 110°(W);110°(H) | 110°(W);110°(H) | 110°(W);110°(H) |
| Refresh Rate | ≥1,920 HZ | ≥1,920 HZ | ≥1,920 HZ | ≥1,920 HZ |
| Input Voltage | AC 110V-220V±10% | AC 110V-220V±10% | AC 110V-220V±10% | AC 110V-220V±10% |
| Max.Power Consumption | ≤950W/m² | ≤690W/m² | ≤780W/m² | ≤880W/m² |
| Avg.Power Consumption | 380W/m² | 275W/m² | 320W/m² | 350W/m² |
| Storage Temperature | -20 ℃~+50℃ | -20 ℃~+50℃ | -20 ℃~+50℃ | -20 ℃~+50℃ |
| Working Temperature | -35 ℃~+85 ℃ | -35℃~+85℃ | -35℃~+85℃ | -35℃~+85℃ |
| Working Humidity | 10%-95% | 10%-95% | 10%-95% | 10%-95% |
| Lifespan | ≥9,000 hours | ≥9,000 hours | ≥9,000 hours | 29,000 hours |
| (50% brightness) | ||||
| Maintenance Mode | Front/Rear | Front/Rear | Front/Rear | Front/Rear |
