Variety of unit modules sizes are available. Seamless match perfect for diferent cabinet sizes. SMD package offers wide viewing angle. Offers super high defnition image quality. Top grade quality, high end confguration, wholesale price.
| IM | |||||
| Technical Specifcations | P 2.5 | P3 | P3.91 | P4 | P4.81 |
| Pixel Pitch | 2.5 mm | 3 mm | 3.91mm | 4 mm | 4.81 mm |
| Pixel Configuration | SMD2121 | SMD2121 | SM02121 | SMD2121 | SMD2121 |
| Module Size | 160x160mm | 192×192mm | 250×250mm | 256×128 mm | 250×250mm |
| 320x160mm | 256×256 mm | ||||
| Module Resolution | 64×64 dots | 64×64 dots | 64×64 dots | 64x32 dots | 52×52 dots |
| 128×64 dots | 64×64dots | ||||
| Pixel Resolution | 160,000 dots/m² | 111,111 dots/m² | 65,536 dots/m² | 62,500 dots/m² | 43.,264 dots/m² |
| Best Viewing Distance | 3m-18m | 3m-20m | 4m-20m | 4m-30m | 5m-30 m |
| Brightness | 1,200 cd//m² | 1,100 cd//m² | 1,200 cd//m² | 1,200 cd//m² | 800-1,000 cd//m² |
| View Angel | 160°(W);120°(H) | 160°(W);120°(H) | 160°(W);120°(H) | 160°(W);120°(H) | 160°(W);120°(H) |
| Refresh Rate | ≥1,920HZ | ≥1,920HZ | ≥1,920HZ | ≥1,920HZ | ≥1,920 H2 |
| Input Voltage | AC 110V-220V±10% | AC 110V-220V±10% | AC 110V-220V±10% | AC 110V-220V±109% | AC 110V-220V±10% |
| Max.Power Consumption | ≤780W/m² | ≤680W/m² | ≤700W/m² | ≤700W/m² | ≤480W/m² |
| ≤488W/m² | ≤345W/m² | ||||
| Avg.Power Consumption | 310W/m² | 270W/m² | 280W/m² | 280W/m² | 190W/m² |
| 200W/m² | 130W/m² | 130W/m² | |||
| Storage Temperature | -20 ℃~+50℃ | -20 ℃~+50℃ | -20 ℃~+50℃ | -20 ℃~+50℃ | -20 ℃~+50℃ |
| Working Temperature | -35 ℃~+85 ℃ | -35 ℃~+85 ℃ | -35 ℃~+85 ℃ | -35 ℃~+85 ℃ | -35 ℃~+85 ℃ |
| Working Humidity | 10%-95% | 10%-95% | 10%-95% | 10%-95% | 10%-95% |
| Lifespan | ≥9,000 hours | ≥9,000 hours | ≥9,000 hours | ≥9,000 hours | ≥9,000 hours |
| (50% brightness) | |||||
| Maintenance Mode | Front/Rear | Front/Rear | Front/Rear | Front/Rear | Front/Rear |
| IM | ||||
| Technical Specifcations | P5 | P6 | P7.62 | P 10 |
| Pixel Pitch | 5 mm | 6 mm | 7.62 mm | 10 mm |
| Pixel Configuration | SMD2121 | SMD3528 | SMD3528 | SMD3528 |
| Module Size | 320×160 mm | 192×192 mm | 244×244 mm | 320×160 mm |
| 384×192 mm | ||||
| Module Resolution | 64×32 dots | 32×32 dots | 32×32 dots | 32×16 dots |
| 64×32 dots | ||||
| Pixel Resolution | 40,000 dots/m² | 27,777 dots/m² | 17,222 dots/m² | 10,000 dots/m² |
| Best Viewing Distance | 5m-30m | 6m-40m | 8m-50m | 10m-50m |
| Brightness | 1,000 cd/m² | 1,000-2,600 cd/m² | 800-1,300 cd/m² | 800-1,500cd/m² |
| View Angel | 160°(W);110°(H) | 160°(W);110°(H) | 160°(W);110°(H) | 160°(W);110°(H) |
| Refresh Rate | ≥1,920 HZ | ≥1,920 HZ | ≥1,920 HZ | ≥1,920 HZ |
| Input Voltage | AC 110V-220V±10% | AC 110V-220V±10% | AC 110V-220V±10% | AC 110V-220V±10% |
| Max.Power Consumption | ≤500W/m² | ≤600W/m² | ≤260W/m² | ≤300W/m² |
| ≤350W/m² | ||||
| Avg.Power Consumption | 200W/m² | 240W/m² | 100W/m² | 120W/m² |
| 140W/m² | ||||
| Storage Temperature | -20 ℃~+50℃ | -20 ℃~+50℃ | -20℃~+50℃ | -20℃~+50℃ |
| Working Temperature | -35 ℃~+85 ℃ | -35℃~+85℃ | -35℃~+85℃ | -35 ℃~+85 C |
| Working Humidity | 10%~95% | 10%~95% | 10%~959% | 10%~95% |
| Lifespan | ≥9,000 hours | ≥9,000 hours | ≥9,000 hours | ≥9,000 hours |
| (50% brightness) | ||||
| Maintenance Mode | Front/Rear | Front/Rear | Front/Rear | Front/Rear |
