Suitable for a variety of installation environments | Perfect Flatness
| Pixel Pitch | P1.25 | P1.53 | P1.86 | P2.5 | P3.076 |
| LED Type | SMD1010 | SMD1212 | SMD1515 | SMD1515 | SMD2020 |
| Physical Density (dots/m²) | 640000 | 428613 | 288906 | 160000 | 105625 |
| Module Resolution | 256×128 | 209×105 | 172×86 | 128×64 | 104×52 |
| Module Size(WxH) | 320×160 | 320×160 | 320×160 | 320×160 | 320×160 |
| Cabinet Size(mm) | 640×480mm(standard) | ||||
| 640×640mm or 320×640mm | |||||
| Cabinet Resolution | 512×384 | 418×314 | 344×258 | 256×192 | 208×156 |
| or 512×512 | or 418×418 | or 344×344 | or 256×256 | or 208×208 | |
| or 256×512 | or 209×418 | or 172×344 | or 128×256 | or 104×208 | |
| Cabinet Weight(kg) | 7.5kg | 7.5kg | 7.5kg | 7.5kg | 7.5kg |
| Maintenance Mode | Front service | Front service | Front service | Front service | Front service |
| Cabinet Material | Die-casting Aluminum | Die-casting Aluminum | Die-casting Aluminum | Die-casting Aluminum | Die-casting Aluminum |
| Brightness | 600-800cd | 600-800cd | 600-800cd | 600-800cd | 600-800cd |
| Viewing angle(H/V) | 160°/160° | 160°/160° | 160°/160° | 160°/160° | 160°/160° |
| The best viewing distance | ≥1.25m | ≥1.53m | ≥1.86m | ≥2.5m | ≥3.076m |
| Drive Mode | Static,1/64 | Static,1/52 | Static,1/43 | Static,1/32 | Static,1/26 |
| Grey Level | 14 bit | 14 bit | 14 bit | 14 bit | 14 bit |
| Refresh Rate(Hz) | 3840 | 3840 | 3840 | 3840 | 3840 |
| Max Power Consumption(W/m²) | 500 | 500 | 500 | 500 | 500 |
| Average Power Consumption(W/m²) | 165-260 | 165-260 | 165-260 | 165-260 | 165-260 |
| IP Grade | IP43 | IP43 | IP43 | IP43 | IP43 |
| Input Power | AC110-240V, 50/60Hz | ||||
| Working Temperature/Humidity (℃/RH) | -20-50℃/35%-75% | ||||
| Storage Temperature/Humidity (℃/RH) | -20-50℃/35%-75% | ||||
| LED Display Type | Small pixel pitch | ||||
