| Technical Parameters | ||
| Panel Parameter | Panel Type | 43",55" LCD Panel |
| Display Size | 43'': 943×531mm; 55'': 1209.6×680.4mm | |
| Display Scale | 16:9 | |
| Backlight type | Patented LED backlight modular component +Constant current source driving component | |
| Resolution | 1080*1920 | |
| Display Colors | 16.7M | |
| Brightness | 1800cd/m² | |
| Contrast | 3500:1 | |
| Visual Angle | 178°(H)/178°(V) | |
| Response Time | 5ms | |
| Colors Mode | PAL/NTSC/SECAM | |
| Working Life | 60000 hours | |
| Main board Parameter | CPU | Cortex-A7 architecture,Main Frequency:1.2G |
| Memory | DDR31G | |
| Built-in storage | Support 32GB TF card maximally | |
| Decoding Resolution | Support 1080P maximally | |
| O/S | Android 7.1.1 | |
| Network | Ethernet,WiFi | |
| Video Play | Support AVI(H.264、DIVX、DIVX、XVID),rm,rmvb, MKV(H.264、DIVX、DIVX、XVID),WMV,MOV, MP4(H.264、MPEG、DIVX、XVID),DAT(VCD format),VOB(DVD format),PMP,MPEG,.MPG., FLV(H.263,H.264),ASF,TS,TP,3GP,MPG etc. | |
| Pictures Format | Support BMP、JPEG、PNG、GIF | |
| USB2.0 Port | Two USB2.0 standard port and two USB expansion port | |
| System Upgradation | Support upgradation by USB,SD card and remote | |
| Battery Parameter | Battery | Blade battery,with long usage time and stable performance |
| Charging time | 7 hours | |
| Working time | 14 hours | |
| Battery capacity | 50000 mAh | |
| Input voltage | 24V | |
| Working Environment | Working temperature | -50℃~110℃ |
| Storage Temperature | -45℃~80℃ | |
| Working humidity | 10%～90% | |
| Storage humidity | 10%～90% | |
| Input power supply | AC100V～240V | |
| Power supply consumption | ≤100W | |
| Standby consumption | ≤3W | |
| Housing colors | Silver,Grey,White,Black,Red | |
| Housing material | Galvanized steel sheet+Outdoor painting | |
| Net weight | 43": 50Kg; 55": 65Kg | |
| Gross weight | 43": 58Kg; 43": 87Kg | |
| Product size | 43": 1236mm*148mm*588mm 55": 1400mm*148mm*756mm | |
| Package size | 43": 1350mm*300mm*700mm 55": 1550mm*300mm*900mm | |
1. Fully galvanized steel plate housing, outer surface with imported metallic painting, anti-magnetic, anti-static, IP65 waterproof.
2. Strict electrical protection: Electrical leakage protection,overload protection, over voltage protection, lightning protection devices, overheat protection,etc.
3. Speakers：Dual-channel, stereo surround sound amplifier system,Output power: 8Ω , 2 × 10W.
4. Working environment: +110°~ -50° , Air-cooled structure for heat dissipation,Military-grade heat dissipation with aluminum substrate.
5. Tempered glass: 6mm AR tempered laminated glass.
6. All the systems of the entire machine adopt the modular design principle, with considerations for sustainability and maintainability.
7. Light sensing system: Automatic adjustment of ambient light brightness for anti-glare control, Images can still be clearly visible even in a strong sunlight environment.
1. High lighting LED back lighting LCD screen, Brightness 1800nits.
2. 1920 x1080 resolution, images can still be clearly visible even in a strong sunlight environment.
3. Outdoor rainproof and heat-resistant metal housing.
