Micro-COB-63J Series PRODUCT
| Name | Category | 63J12 | 63J15 |
| Module | Pixel Structure | COB | COB |
| Parameter | Pixel Pitch(mm) | 1.25 | 1.56 |
| Module Size(mm) | 150x168.75 | 150x168.75 | |
| Module Resolution (W×H) | 120*135 | 96*108 | |
| Cabinet | Unit Composition (W×H) | 4*2 | 4*2 |
| Parameter | Cabinet Size(mm) | 600x337.5x28 | 600x337.5x28 |
| Cabinet Resolution (W×H) | 480*270 | 384*216 | |
| Dimension(m²) | 0.2025 | 0.2025 | |
| Pixel Density (Dots/m²) | 640000 | 409600 | |
| Material | Die-cast Aluminum | Die-cast Aluminum | |
| Cabinet Weight(kg) | 4.7Kg | 4.7Kg | |
| Cabinet Flatness | ≤0.1mm | ≤0.1mm | |
| Optics | Brightness | 0-1000cd/m²(adjustable) | 0-1000cd/m²(adjustable) |
| Parameter | Color Temperature(K) | 2000-12000(adjustable) | 2000-12000(adjustable) |
| Viewing Angle (HM) | 170°/170° | 170°/170° | |
| Center Distance Deviation of | <3% | <3% | |
| Luminescent Point | |||
| Luminance Uniformity | ≥98% | ≥98% | |
| Color Uniformity | Within ±0.0035Cx,Cy | Within ±0.0035Cx,Cy | |
| Contrast Ratio | 1000000:1 | 1000000:1 | |
| Electric | Peak Power Consumption | ≤500W/m² (Tested at 600 nits white | ≤500W/m² (Tested at 600 nits white |
| Parameter | balance) | balance) | |
| Average Power Consumption | 200W/m² | 200W/m² | |
| Power Supply | AC100~240V(50~60Hz) | AC100~240V(50~60Hz) | |
| Process | Driving Mode | Constant current drive | Constant current drive |
| performance | Frame Frequengy | 50/60Hz | 50/60Hz |
| Refresh Rate | 3840Hz | 3840Hz | |
| Gray Scale | 14bit | 14bit | |
| Application | Operating Temperature | -20℃~+60℃ | -20℃~+60℃ |
| Parameter | Operating Humidity | 10%~90% RH anti-fog | 10%~90% RH anti-fog |
| Service Life | ≥100,000Hrs | ≥100,000Hrs | |
| Maintenance Mode | Full Front maintenance | Full Front maintenance | |
| Protection Grade | IP54 | IP54 | |
| Certification Type | CCC, CE, FCC | CCC, CE, FCC | |
| LED Display Type | Small pixel pitch | ||
Efficient Heat Dissipation: High precision seamless splicing, silent and fanless design, die-cast aluminum body;
Low Power Consumption: Common cathode circuit design, achieving energy-saving and low power consumption, high refresh rate, HDR high dynamic image display, 16-bit high grayscale and low brightness;
High Protection: Full flip-chip COB integrated packaging, high protection, high reliability, high environmental adaptability;
Dual Redundancy: Supports dual backup for power and signal;
Easy Maintenance: Full front maintenance, featuring hot-swappable modules, and overall rigid connection.
