The internal hexagonal wrench can be used to quickly assemble, disassemble, and maintain the modulefrom the front. Simple lock design, easy front and back maintenance, four locks in one module, only 8s installation, save time and labor cost.
| Pixel Pitch | P2.97 | P3.91 | P4.81 | P6.25 | P7.81 | P10.42 |
| LED Type | SMD1415 | SMD1921 | SMD1921 | SMD2727 | SMD2727 | SMD2727 |
| Physical Density (dots/m²) | 112896 | 65536 | 43264 | 25600 | 16384 | 9216 |
| Module Resolution | 168×84 | 128×64 | 104×52 | 80×40 | 64×32 | 48×24 |
| Module Size(mm) | 500×250 | |||||
| Cabinet Resolution | 336×336 | 256×256 | 208×208 | 160×160 | 128×128 | 96×96 |
| Cabinet Size(mm) | 1000×1000×72mm (Customizable for 500 / 750 height) | |||||
| Cabinet Weight(kg) | 25kg | |||||
| Maintenance Mode | Front and Back maintenance | |||||
| Cabinet Material | Profile cabinet | |||||
| Brightness | 4500-10000cd | 6000-10000cd | 6000-10000cd | 6000-12000cd | 6000-12000cd | 6000-12000cd |
| Color Temperature(K) | 5000-12000 Optional | 5000-12000 Optional | 5000-12000 Optional | 5000-12000 Optional | 5000-12000 Optional | 5000-12000 Optional |
| Viewing angle(H/V) | 140°/160° | |||||
| Grey Level | 16 bit | |||||
| Contrast Ratio | 10000:1 | |||||
| Frame Frequency | 50/60 | |||||
| Refresh Rate(Hz) | 3840Hz | |||||
| Drive Mode | Static,1/21 Scan | Static,1/16 Scan | Static,1/13 Scan | Static,1/8 Scan | Static,1/4 Scan | Static,1/2 Scan |
| The best viewing distance | 3-100m | 4-100m | 4-100m | 6-150m | 8-150m | 10-200m |
| Max Power Consumption(W/m²) | 800 | 650 | 650 | 650 | 650 | 650 |
| Average Power Consumption(W/m²) | 200-300 | 100-200 | 100-200 | 100-200 | 100-200 | 100-200 |
| IP Grade | IP65 | IP65 | IP65 | IP65 | IP65 | IP65 |
| Input Power | AC90-264V,47-63 Hz | |||||
| Working Temperature/Humidity (℃/RH) | -20-60℃/10%-85% | |||||
| Storage Temperature/Humidity (℃/RH) | -20-60℃/10%-85% | |||||
