Indoor XR LED Display P1.95,P2.604,P2.97,P3.91
| XR-IR3 Z Series Parameters | |||||
| Item | P1.95 | P2.6 | P2.6 | P2.97 | P3.91 |
| Pixel Pitch | 1.95mm | 2.604mm | 2.604mm | 2.976mm | 3.91mm |
| LED Type | Professional SMD1515 | Professional SMD1515 | Professional SMD1515 | Professional SMD2020 | Professional SMD2020 |
| Module Resolution | 128dots x 128dots | 96dots x 96dots | 96dots x 96dots | 84dots x 84dots | 64dots x 64dots |
| Driving Mode | 1/16 scan | 1/16 scan | 1/8 scan | 1/14 scan | 1/8 scan |
| Module Pixels | 16,384dots | 9,216dots | 9,216dots | 7,056dots | 4,096dots |
| Module Size(mm) | 250 x 250 | 250 x 250 | 250 x 250 | 250 x 250 | 250 x 250 |
| Cabinet Size(mm) | 500 x 500/1000 | 500 x 500/1000 | 500 x 500/1000 | 500 x 500/1000 | 500 x 500/1000 |
| Cabinet Resolution(dots) | 256 x 256/512dots | 192 x 192/384dots | 192 x 192/384dots | 168 x 168/336dots | 128 x 128/256dots |
| Pixel Density(dots/m²) | 282,144 | 147,456 | 147,456 | 112,896 | 65,536 |
| Minimum Viewing Distance | ≥1.9m | ≥2.6m | ≥2.6m | ≥2.9m | ≥3.9m |
| Contrast Ratio | 10000:1 | 10000:1 | 10000:1 | 10000:1 | 10000:1 |
| Brightness | 1500~2000cd | 1500~2000cd | 1500~2000cd | 1500cd | 1500cd |
| IP Grade | IP43 | IP43 | IP43 | IP43 | IP43 |
| Refresh Rate | 7,680Hz | 7,680Hz | 7,680Hz | 7,680Hz | 7,680Hz |
| Receiving Card | Nova A10S-PRO | Nova A10S-PRO | Nova A10S-PRO | Nova A10S-PRO | Nova A10S-PRO |
| Gray Scale | 8~12bits | 8~12bits | 8~12bits | 8~12bits | 8~12bits |
| Viewing Angle | 160°/160° | 160°/160° | 160°/160° | 160°/160° | 160°/160° |
| Maximum Power Consumption | 520(W/m²) | 520(W/m²) | 520(W/m²) | 520(W/m²) | 520(W/m²) |
| Average Power Consumption | 175(W/m²) | 175(W/m²) | 175(W/m²) | 175(W/m²) | 175(W/m²) |
| Inout Voltage | AC110V~AC220V | AC110V~AC220V | AC110V~AC220V | AC110V~AC220V | AC110V~AC220V |
| 120Hz | 120~240Hz | 120~240Hz | 120Hz | 120~240Hz | |
| Operating Temperature | -20℃~60℃ | -20℃~60℃ | -20℃~60℃ | -20℃~60℃ | -20℃~60℃ |
| Operating Humidity | 10%~90% | 10%~90% | 10%~90% | 10%~90% | 10%~90% |
| Cabinet Material | Die-casting Aluminum | Die-casting Aluminum | Die-casting Aluminum | Die-casting Aluminum | Die-casting Aluminum |
| Cabinet Weight | 7.5kg/panel | 7.5kg/panel | 7.5kg/panel | 7.5kg/panel | 7.5kg/panel |
| Operating System | Windows (Win7,Win8,etc.) | Windows (Win7,Win8,etc.) | Windows (Win7,Win8,etc.) | Windows (Win7,Win10,etc.) | Windows (Win7,Win10,etc.) |
| Signal Source Compatibility | DVI,HDMI1.3,DP1.2, | DVI,HDMI1.3,DP1.2, | DVI,HDMI1.3,DP1.2, | DVI,HDMI1.3,DP1.2, | DVI,HDMI1.3,DP1.2, |
| SDI,HDMI2.0,etc | SDI,HDMI2.0,etc | SDI,HDMI2.0,etc | SDI,HDMI2.0,etc | SDI,HDMI2.0,etc | |
