FI4 T (P0.93, P1.25, P1.56, P1.87)
mini led company
mini led company

FI4 T (P0.93, P1.25, P1.56, P1.87) (600×337.5mm)

FI4T SERIES PRODUCT

This comes to thinks tvs 3rd generation of t-series, with 6.9kg weight and slim, smooth make.


Contact Us PDF Download WhatsApp
FI4 T (P0.93, P1.25, P1.56, P1.87)
Specifications
Features
Installation Method

FI4 T (P0.93,P1.25,P1.56,P1.87) Specifications


ItemT0.93T1.25T1.56T1.87
Pixel pitch0.93mm1.25mm1.56mm1.87mm
Pixel density1137778640000409600285204
Module size300x168.75mm
LED packageMiniLEDSMD1010SMD1212SMD1515
Module resolution(pixels)320x180240x135192x108160x90
Module arrangement per cabinet2x2
Cabinet dimension600x337.5x52mm
Cabinet weight (including module)6.9kg
Cabinet resolution(pixels)640x360480x270384x216320x180
MaintenanceFull front service
System backupSupport
White balance brightness500-800cd/m²
Pixel-livel calibrationSupport
Color temperature6500K  (adjustable)
Refresh rate3840Hz
Viewing angle160°(V/H)
Brightness uniformity≥99%
Grayscale level16bits
Contrast ratio5000:01:00
Scanning mode1/60 scan1/60 scan1/64 scan1/45 scan
Working voltage(input)110-240V, 50/60Hz
Max./Avg.Power consumption500W/m²/165-260W/m²
Storage temperature&humidity (RH)-20°C-50℃&35-75%
Working temperature&humidity (RH)-20°C-50℃&35-75%
IP ratingsIP45
Screen temperature rise≤5℃
InstallationOn-wall/recessed/pedestal/suspended/stacked install
Signal outputHDMI/VGA/DVI/DP
CertificationRoHS/FCC/CE
LED Display TypeSmall pitch LED panel


FI4 T (P0.93, P1.25, P1.56, P1.87) Detailed Information and Features

FI4 T (P0.93, P1.25, P1.56, P1.87) Detailed Information and Features
T SERIES
3RD GENERATION CABINET
This comes to thinks tvs 3rd generation of t-series, with6.9kg weight and slim, smooth make.
PRODUCT DIMENSION
PRODUCT DIMENSION

  • Flash silver and black matte to choose forthe cabinet

  • Double power & signal system design to handle any unexpected emergency.

  • Memory on board ensuring efforts to switch modules freely and store calibration data.

  • 16:9 aspect ratio for easy, setting up screen and pixel-to-pixel screen quality.


INSTALLATION
INSTALLATION

With four locating pins on top and one ball punger, and handy cabinet locks, all installtion will facilitateand be fixed firmly.

LOW GRASCALE LEVELHIGH LUMINANCE
LOW GRASCALE LEVELHIGH LUMINANCE

High grayscale levels, high refresh rates, high contrastratios at low-iluminant brightness.

DYNAMIC,ENERGY SAVING
DYNAMIC,ENERGY SAVING
Screen detects darkened gradient parts and decideds smartly so as to enhance contrast and save energy.


WIDE VIEWING ANGLES
WIDE VIEWING ANGLES
It gives you better visual exeperience at variousangles and positions.


HIGH DYNAMIC RANGE(HDR)
HIGH DYNAMIC RANGE(HDR)
It supports HDR which ensures the screen brilliant colors and luminance, and best performance for dim quality of media content.


FI4 T (P0.93, P1.25, P1.56, P1.87) Installation Method

Wall surface mount
Wall surface mount
Floor stand mount
Floor stand mount
Concave structure
Concave structure
H-shaped structure
H-shaped structure
Suspended mount
Suspended mount
