This product is only applicable to the indoor Mini COB product 320*160 module series.
| Parameter name | Product spacing | |||
| Modules | Pitch | 1.25 | 1.53 | 1.86 |
| LED Type | Full flip chip | |||
| Module resolution | 256*128 | 208*104 | 172*86 | |
| Module size(mm*mm) | 320*160 | |||
| Module weight (kg) | About 0.5kg | |||
| Scanning method | 64 scans | 52 scans | 43 scans | |
| Module supply voltage | ≥DC 4.5V(recommended) | |||
| Flash correction storage | support | |||
| Pixel density(dots/m²) | 640000 | 422753 | 288906 | |
| Photoelectric parameters | Single point brightness correction | support | ||
| Single-point color correction | support | |||
| White balance brightness(nit) | 60pnit(after correction) | |||
| Color temperature(K) | 9300K | |||
| Horizontalvertical viewing angle | 160° | |||
| Brightness uniformity | ≥95% | |||
| Chromatic uniformity | ±0.003 Cx,Cy | |||
| Contrast | ≥10000:1 | |||
| Single module current | About 4.0A | About 2.4A | About 2.4A | |
| Single module power consumption (DC4.5V) | About 19W | About 11W | About 11W | |
| Processing performance | Frame rate(Hz) | 60 | ||
| Refresh rate(Hz) | 3840 | |||
| Drive mode | Constant current drive | |||
| Grayscale(bit) | 13bit | |||
| Using Parameters | Typical ifespan (hrs) | ≥100,000 | ||
This specification is only applicable to the indoor Mini COB product 320*160 module series
1) Fuly flip-chip LED chips offer zero image retention, no "caterpillar" artifacts, and low powerconsumption.
2)Matte finish, non-reflective, and high contrast.
3) COB package, dust- and moisture-resistant, with a 4H surface hardness and washability
4) Selected PWM driver lCs deliver smooth grayscale transitions and high refresh rates.resulting in vivid, vibrant images.
5) Using industry-standard 320*160 module dimensions and mounting holes6)Using low-voltage drivers for a low-power cooling screen.
